Description
ASG-Weichai Series:50HZ | ||||||||||
Model |
Specification 50HZ 400-230V |
General specifications | Alternator | Dimensions | Weight (kg) | |||||
ESP | PRP | Engine type | Consumption 100% | Gov | ||||||
KVA | KW | KVA | KW | L/H | ||||||
WEICHAI GROUP DEUTZ | ||||||||||
GW33 | 33 | 26 | 30 | 24 | D226B-3D | 9.8 | Electrical | ASG164D | 1850*680*910 | 690 |
GW55 | 55 | 44 | 50 | 40 | TD226B-3D | 12.8 | Electrical | ASG184E | 2260*790*1160 | 920 |
GW69 | 69 | 55 | 63 | 50 | WP4D66E200 | 13.8 | Electrical | ASG184F | 2400*930*1300 | 1320 |
GW110 | 110 | 88 | 100 | 80 | WP4D100E200 | 22.1 | Electrical | ASG274C | 2600*1030*1440 | 1520 |
GW113 | 113 | 90 | 102 | 82 | WP40108E200 | 22.6 | Electrical | ASG274C | 2600*1080*1540 | 1520 |
GW138 | 138 | 110 | 125 | 100 | WP6D l 32E200 | 27.2 | Electrical | ASG274D | 3000*1110*1640 | 1890 |
GW165 | 165 | 132 | 150 | 120 | WP6D 152E200 | 32 | Electrical | ASG274E | 3100*1140*1680 | 1890 |
WEICHAI GROUP STEYR | ||||||||||
GW206 | 206 | 165 | 188 | 150 | WP10D200E200 | 41.8 | Electrical | ASG274G | 3700*1050*2100 | 2270 |
GW248 | 248 | 198 | 225 | 180 | WP10D238E200 | 42.7 | Electrical | ASG274J | 3700*1150*2100 | 2420 |
GW275 | 275 | 220 | 250 | 200 | WP10D264E200 | 47.4 | Electrical | ASG274K | 3800*1160*2160 | 2650 |
GW344 | 344 | 275 | 313 | 250 | WP12D317E200 | 59.3 | Electrical | ASG314D | 4000*1230*2160 | 2870 |
GW413 | 413 | 330 | 375 | 300 | WP13D385E200 | 71.1 | Electrical | ASG314F | 4400*1430*2250 | 4850 |
WEICHAI GROUP Baudouin | ||||||||||
GW495 | 495 | 396 | 450 | 360 | 6M26D447E200 | 85.4 | Electrical | ASG314F | 4200*1350*2100 | 3730 |
GW550 | 550 | 440 | 500 | 400 | 6M260484E200 | 100 | Electrical | ASG354C | 4230*1450*2200 | 4100 |
GW633 | 633 | 506 | 575 | 460 | 6M33D572E200 | 106 | Electrical | ASG544C | 4400*1550*2300 | 4400 |
GW688 | 688 | 550 | 625 | 500 | 6M33D605E200 | 116 | Electrical | ASG544E | 4500*1650*2300 | 4730 |
GW880 | 880 | 704 | 800 | 640 | 12M26D792E200 | 130 | Electrical | ASG634B | 4760*2138*2295 | 5080 |
GW1001 | 1001 | 801 | 910 | 728 | 12M26D902E200 | 146 | Electrical | ASG634C | 5060*2238*2430 | 5480 |
GW1100 | 1100 | 880 | 1000 | 800 | 12M33D968E200 | 158 | Electrical | ASG634D | 5460*2438*2480 | 5680 |
GW1249 | 1249 | 999 | 1135 | 908 | 12M33D1108E200 | 170 | Electrical | ASG634E | 5660*2538*2630 | 5980 |
GW1375 | 1375 | 1100 | 1250 | 1000 | 12M33D1210E200 | 186 | Electrical | ASG634G | 5860*2638*2730 | 6180 |
WEICHAI GROUP YANGCHAI | ||||||||||
GW21 | 21 | 17 | 19 | 15 | WP2.1D18E2 | 7.1 | Electrical | ASG164C | 1700*620*1000 | 570 |
GW25 | 25 | 20 | 23 | 18 | WP2.5D22E2 | 8.1 | Electrical | ASG164D | 1860*710*1030 | 630 |
GW33 | 33 | 26 | 30 | 24 | WP3.9D33E2 | 9.6 | Electrical | ASG184F | 1950*720*1010 | 690 |
GW413 | 41 | 33 | 38 | 30 | WP4.3D38E2 | 10.6 | Electrical | ASG184G | 2160*750*1100 | 820 |
GW48 | 48 | 39 | 44 | 35 | WP4.6D44E2 | 11.5 | Electrical | ASG184G | 2260*850*1220 | 890 |
GW62 | 62 | 50 | 56 | 45 | WP4.1D50E2 | 13.6 | Electrical | ASG224C | 2360*850*1330 | 920 |
GW69 | 69 | 55 | 63 | 50 | WP4.3D61E2 | 13.7 | Electrical | ASG224E | 2400*930*1200 | 1320 |
ASG-Weichai Series:60HZ | ||||||||||
Model |
Specification 60HZ 400-230V |
General specifications | Alternator | Dimensions | Weight (kg) | |||||
ESP | PRP | Engine type | Consumption 100% | Gov | ||||||
KVA | KW | KVA | KW | L/H | ||||||
WEICHAI GROUP DEUTZ | ||||||||||
GW69 | 69 | 55 | 63 | 50 | WP4D66E201 | 13.8 | Electrical | ASG184F | 2400*930*1300 | 1320 |
GW110 | 110 | 88 | 100 | 80 | WP4D100E201 | 22.1 | Electrical | ASG274C | 2600*1030*1440 | 1520 |
GW124 | 124 | 99 | 113 | 90 | WP4D118E201 | 25.2 | Electrical | ASG274C | 2700*1030*1540 | 1520 |
GW138 | 138 | 110 | 125 | 100 | WP6D132E201 | 27.2 | Electrical | ASG274D | 3100*1060*1640 | 1890 |
GW165 | 165 | 132 | 150 | 120 | WP6D158E200 | 32 | Electrical | ASG274E | 3200*1130*1740 | 1890 |
GW186 | 186 | 149 | 169 | 135 | WP6D180E201 | 38.6 | Electrical | ASG274G | 3260*1180*1840 | 1990 |
WEICHAI GROUP STEYR | ||||||||||
GW206 | 206 | 165 | 188 | 150 | WP10D200E201 | 41.8 | Electrical | ASG274G | 3700*1050*2100 | 2270 |
GW248 | 248 | 198 | 225 | 180 | WP10D238E201 | 42.7 | Electrical | ASG274J | 3800*1150*2200 | 2420 |
GW275 | 275 | 220 | 250 | 200 | WP10D264E201 | 47.4 | Electrical | ASG274K | 3830*1150*2260 | 2650 |
GW309 | 309 | 248 | 281 | 225 | WP12D288E201 | 52.2 | Electrical | ASG314C | 3900*1250*2300 | 2680 |
GW344 | 344 | 275 | 313 | 250 | WP12D317E201 | 59.3 | Electrical | ASG314D | 4400*1430*2300 | 4850 |
GW413 | 413 | 330 | 375 | 300 | WP13D385E201 | 71.1 | Electrical | ASG314F | 4460*1530*2320 | 4850 |
WEICHAI GROUP Baudouin | ||||||||||
GW495 | 495 | 396 | 450 | 360 | 6M26D447E201 | 85.4 | Electrical | ASG314F | 4100*1250*2100 | 3730 |
GW578 | 578 | 462 | 525 | 420 | 6M26D484E201 | 100 | Electrical | ASG354C | 4400*1550*2200 | 4100 |
GW633 | 633 | 506 | 575 | 460 | 6M33D572E200 | 106 | Electrical | ASG544C | 4460*1650*2300 | 4400 |
GW688 | 688 | 550 | 625 | 500 | 6M33D605E200 | 116 | Electrical | ASG544E | 4460*1650*2300 | 4730 |
GW882 | 880 | 704 | 800 | 640 | 12M26D792E200 | 130 | Electrical | ASG634B | 4860*2138*2495 | 5080 |
GW1001 | 1001 | 801 | 910 | 728 | 12M26D902E200 | 146 | Electrical | ASG634C | 5060*2338*2530 | 5480 |
GW1100 | 1100 | 880 | 1000 | 800 | l 2M26D968E200 | 158 | Electrical | ASG634D | 5360*2538*2580 | 5680 |
GW1249 | 1249 | 999 | 1135 | 908 | 12M33D1108E20C | 170 | Electrical | ASG634E | 5660*2638*2630 | 5980 |
GW1375 | 1375 | 1100 | 1250 | 1000 | 12M33D1210E200 | 186 | Electrical | ASG634G | 5860*2738*2730 | 6180 |
