Description
MY SERIES SINGLE-PHASE CAPACITOR RUN
ASYNCHRONOUS INDUCTION MOTOR
FEATURE
MY Series Aluminum housing single-phase one capacitor-run asynchronous motors, with latest design in entirety, are made of quality materials and meet the relative rules of IEC standard. MY motors have good performance, safe and reliable operation, nice appearance, and can be maintained very conveniently, while with low noise, little vibration, light weight and simple construction. This series motors can be used on household appliance, pumps, fan and recording meters,etc.
OPERATING CONDITIONS
Ambient temperature:-15℃≤θ≦40℃
Protection:IP54/IP55
Insulation Class:F/H
Rated Voltage:220V or any voltage between 110-240V
Frequency:50HZ/60HZ
Duty:S1(continuous)
Above sea level:not exceed 1000m
Cooling method:IC0141
